MULTIMEDIA SERIES

Products Features

‧ V2 Type keytop. (Normal Keycap)

‧ Multilingual compatible.

‧ Full layout.

‧ 5 Media hot keys.

‧ 5 Internet hot keys.

‧ 2 Windows hot keys.



Function Key
Volume Down : Hold down this key to quick decrease the volume.
Volume Up : Hold down this key to quick increase the volume.
Stop : Stop the music or movie that is playing.
Play/Pause : Play or pause music or a movie. Once paused, press this key again to resume playing.
Media Select : Press this button to open media payer.
Calculator : Start microsoft calculator.
Internet Browser : Press this button to launch default internet browser.
Email : Start the default e-mail program. If you are not sure what the default e-mail program Is, press this key to find out.
Refresh : Update the information on an active web page or the contents of a particular window.
Back : Go back to the previously viewed item in programs that support the "Back" command, such as a web browser.
Forward : Go to the next item-if it was previously viewed in the same session-in programs that support the "Forward" command, such as a web browser.
Sleep : User can put the system into sleep mode, if the PC supports power management. The user can put the computer to sleep by press this key. It will protect data and saving energy. To press the power key or sleep key again will a wake the computer (In some case, press any key will a wake computer also). If power management is not enabling, this key will not work. The "Sleep" hot key functionality is only available if your system supports power management (ACPI), all the peripherals (e.g. VGA, Sound Card…) require to compatible with the power management also.


Products Specification

Key numbers

103 / 104 / 105 / 106 / 108

Pitch

19mm

Total height

21.8mm

Travel

3.8 ± 0.2mm

Multimedia hot key

○

Internet hot key

○

Windows hot key

○

Power sleep key

╳

Scroll, click, and zoom

╳

USB 2.0 hub

╳

Embeded metal plate design

╳

Interface

PS2 / USB

Dimension

461(L) x 181(W) x 26(H)mm

Weight

650 ± 20g
